Stainless Steel Metric Cable Glands

info« prev 1 2 3 4 5 next »

IP68 PERFECT STAINLESS STEEL CABLE GLANDS

Features

Measurement: Metric

Rated up to IP68

Made From Stainless Steel

Temperature Range of -20°C to +100°C

Product Code	Size	L (mm)	H (mm)	ØC (mm)
50.612 ES	M12	25	5	3-6
50.616 ES	M16	30	5	5-9
50.620 ES	M20	33.5	6	9-13
50.625 ES	M25	36.5	7	11-16
50.632 ES	M32	38	8	14-21
50.640 ES	M40	41	8	19-27
50.650 ES	M50	49.5	9	24-35
50.663 ES	M63	52.5	10	32-42

IP68 PERFECT EMC GLAND STAINLESS STEEL

Features

Measurement: Metric

Rated up to IP68

Made From Stainless Steel

Temperature Range of -20°C to +100°C

Product Code	Size	L (mm)	H (mm)	ØC (mm)
50.616 ES/EMV	M16	30	5	5-9
50.620 ES/EMV	M20	33.5	6	9-13
50.625 ES/EMV	M25	36.5	7	11-16
50.632 ES/EMV	M32	38	8	14-21

WADI ONE EMC-CABLE GLAND

Features

Measurement: Metric

Material: Stainless steel 1.4404 / AISI 316L

Sealing insert: TPE TPS

Temperature Range of -60°C to +100°C

Product Code	Size	L (mm)	H (mm)	ØC (mm)
K253-1012-00	M12	25.5	6.5	40-53
K253-1016-00	M16	31.5	7	31-42
K253-1020-00	M20	33	8	24-33
K253-1025-00	M25	35.5	8	17-25.5
K253-1032-00	M32	40.5	9	12.5-20.5
K253-1040-00	M40	43	9	8-15
K253-1050-00	M50	47.5	10	5-10.5
K253-1063-00	M63	53	10	3-8

WADI HEAT EMC-CABLE GLAND

Features

Measurement: Metric

Material: Stainless steel 1.4404 / AISI 316L

Sealing insert: Fluororubber FKM

Temperature Range of -60°C to +100°C

Product Code	Size	L (mm)	H (mm)	ØC (mm)
K258-1012-00	M12	25.5	6.5	40-53
K258-1016-00	M16	31.5	7	8-15
K258-1020-00	M20	33	8	24-33
K258-1025-00	M25	35.5	8	17-25.5
K258-1032-00	M32	40.5	9	40-53
K258-1040-00	M40	43	9	24-33
K258-1050-00	M50	47.5	10	14-20.5
K258-1063-00	M63	53	10	5-10.5

Product Code	Size	L (mm)	H (mm)	ØC (mm)
K258-1012-01	M12	25.5	6.5	5-10.5
K258-1016-01	M16	31.5	7	12.5-20.5
K258-1020-01	M20	33	8	31-42
K258-1025-01	M25	35.5	8	3-8
K258-1032-01	M32	40.5	9	31-42
K258-1040-01	M40	43	9	18-25.5
K258-1050-01	M50	47.5	10	8-15
K258-1063-01	M63	53	10	3-8

IP65 WADI EMC CABLE GLAND SEALING INSERT

Features

Measurement: Metric

Rated up to IP68

Made From Stainless Steel

Temperature Range of up to +200°C

Product Code	Size	L (mm)	H (mm)	ØC (mm)
101011M16ES	M16	25	6	7-11
101016M20ES	M20	26	6	8-15
101021M25ES	M25	31	7.5	13-20
101029M32ES	M32	32	8	18-25

STAINLESS STEEL VENTING ELEMENT

Features

Measurement: Metric

Typical air flow 90 - 130 ml/min/cm²; at Δp = 0,01 bar

Water entry pressure > 1 bar

Temperature range -40°C/+100°C

Protection grade IP66 / IP67 / IP69K

Product Code	Thread Size	Thread Length	Q/A Length	A/F Dim'n
JDAE12ES4305	M12	10	17.8	17

IP68 PERFECT NICKEL PLATED BRASS METRIC IP68 ACCESSORIES & LOCKNUTS

Measurement: Metric

Temperature Range of up to +200°C

Product Code	Size	H (mm)	SW1(mm)	A (mm)
50.212 ES	M12	2.8	14	M12x1.5
50.216 ES	M16	2.8	19	M16x1.5
50.220 ES	M20	3	21	M20x1.5
50.225 ES	M25	3.5	30	M25x1.5
50.232 ES	M32	4	36	M32x1.5
50.240 ES	M40	5	46	M40x1.5
50.250 ES	M50	5	60	M50x1.5
50.263 ES	M63	6	70	M63x1.5
