Nylon Metric Cable Glands - HYCGLGM16

DESCRIPTION

Perfect cable gland PA/SW M16X1,5 thread length 8, min/max cable dia 5-10 Body - Polyamide PA6 V-2. Supplied with Hexagonal locknut PA/SW M16X1,5 thread length M16x1.5 Body - Polyamide PA6 GF30. Colour-Grey

Quote Me Datasheet

CAD Drawing Line Drawing Shop

FEATURES

IP68
Temp range -20°C to +100°C
Quick and easy installation without special tools
Wall thickness 1-4mm

SPECIFICATION

Additional Material Detail	Body - Polyamide PA6 V-2
Product Type	Standard
Body Material	Polyamide
Min Temperature Rating °C	-20
Max Temperature Rating °C	100
IP Rating	68
Colour	Grey RAL7035
Thread Size	M16
Clamping Range Min (mm)	5
Clamping Range Max (mm)	10
External Connecting Thread Type	Metric
Thread Length (mm)	8
Height (mm)	35.5
